PRINCIPAIS CARACTERÍSTICAS
Conexão simplificada
- Ligação com um único cabo USB Type C
- Entrega de energia
- Ligação de rede estável
Gestão de cores fiável
- Sensor incorporado para automatizar o seu fluxo de trabalho
- Software de gestão de cores ColorNavigator 7
- Software de gestão de cores da rede ColorNavigator
Precisão de cores
- Cores vivas reproduzidas nos padrões da indústria
- LUT 3D para exibição de cores precisas
- Exibição simultânea de 10 bits
- Predefinições para transmissão e cinema
Pós-produção
- Ecrã preto verdadeiro
- Suporte Gama HDR
- DCI-4K Cropping
- Aviso de luminância
- Zoom 4K
- Aviso fora da gama BT.709
- Configurações automáticas de cores
Visualização estável de imagens
- Ajustado de fábrica para gradação de cores suaves
- Cor estável em apenas 3 minutos
- Exibição estável utilizando tecnologia AI pioneira no sector
- Uniformidade no ecrã
Conforto e design
- Design em metal perfurado
- Diversas portas de ligação
- Viseira de Proteção contra a Luz
- Suporte ergonómico para melhor conforto e conveniência
Compromisso com a qualidade
- Garantia de 5 anos do fabricante
- Zero pixels brilhantes
- Garantia de brilho e cor
- Certificado para Qualidade e Desempenho
Panel | |
Type | IPS |
Backlight | Wide-Gamut LED |
Size | 26.9" / 68.4 cm |
Native Resolution | 3840 x 2160 (16:9 aspect ratio) |
Viewable Image Size (H x V) | 596.2 x 335.3 mm |
Pixel Pitch | 0.155 x 0.155 mm |
Pixel Density | 164ppi |
Display Colors | 1.07 billion colors, 10-bit display (from a palette of 278 trillion, 16-bit LUT) |
Viewing Angles (H / V, typical) | 178°, 178° |
Brightness (typical) | 500 cd/m2 |
Contrast Ratio (typical) | 1450:1 |
Response Time (typical) | 13 ms (Gray-to-gray) |
Color Gamut (typical) | Adobe RGB: 99%, DCI-P3: 98% |
Video Signals | |
Input Terminals | USB Type-C (DisplayPort Alt Mode, HDCP 2.3), DisplayPort (HDCP 2.3), HDMI (Deep Color, HDCP 2.3) |
Digital Scanning Frequency (H / V) | USB Type-C, DisplayPort: 25 - 137 kHz / 23 - 61 Hz
HDMI: 15 - 135 kHz / 23 - 61 Hz |
USB | |
Upstream | USB 3.1 Gen 1: Type-C (DisplayPort Alt Mode, Power Delivery Source 94 W max.), USB 3.1 Gen 1: Type-B |
Downstream | USB 3.1 Gen 1: Type-A x 2 USB 2.0: Type-A x 2 |
Power | |
Power Requirements | AC 100 - 240 V, 50 / 60 Hz |
Typical Power Consumption | 34W |
Maximum Power Consumption | 225W |
Power Save Mode | 0.5W or less |
Built-in Calibration Sensor | Yes |
Features & Functions | |
Brightness Stabilization | Yes |
Digital Uniformity Equalizer | Yes |
Preset Modes | User, BT.2020, BT.709, DCI-P3, PQ_DCI-P3, HLG_BT.2100, AdobeRGB, sRGB, Calibration (CAL), SYNC_SIGNAL |
OSD Languages | English, German, French, Italian, Japanese, Simplified Chinese, Spanish, Swedish, Traditional Chinese |
Others | Color Adjustment, PQ Option, HLG Option, SelfCalibration, Input Color Format, YUV Color Matrix, Input Range, I/P Conversion, Picture Expansion, Nearest Neighbor, Zoom, DCI 4K Cropping, BT.709 Gamut warning, Luminance Warning, Marker, Menu Rotation, Power Save, Input Skip, Mode Skip, Custom Key, Information Display, Key Lock, DUE Priority, Ethernet
|
Physical Specifications | |
Dimensions (Landscape, W x H x D) | 638 x 415.9 - 570.9 x 245 mm |
Dimensions (Without Stand, W x H x D) | 638 x 390 x 86.2 mm |
Dimensions (Landscape with Hood, W x H x D) | 648 x 420.9 - 575.9 x 346 mm |
Net Weight | 9.8 kg |
Net Weight (Without Stand) | 6.8 kg |
Net Weight (With Hood) | 10.3 kg |
Height Adjustment Range | 155 mm |
Tilt | 35° Up, 5° Down |
Swivel | 344° |
Pivot | 90° |
Hole Spacing (VESA Standard) | 100 x 100 mm |
Environmental Requirements | |
Operating Temperature | 0 - 35 °C |
Operating Humidity (R.H., non condensing) | 20 - 80 % |
Certifications & Standards (Please contact EIZO for the latest information.) | CB, CE, UKCA, TUV/GS, cTUVus, FCC-B, CAN ICES-3 (B), TUV/S, PSE, VCCI-B, RCM, EAC, RoHS, WEEE, TUV/Ergonomics |
Proprietary Software | |
Color Mangement Software ColorNavigator 7 | Supported |
Supplied Accessories (May vary by country. Please contact EIZO for details.) | |
Signal Cables | USB Type-C (2 m), HDMI (2 m) |
Others | AC power cord, USB Type-A - USB Type-B cable (2 m), Setup guide, Factory Report, ScreenCleaner, Monitor hood, Warranty card
|
Warranty | Five Years 2 5 Zero bright sub-pixels for six months from date of purchase |
- 2 With current LCD technology, a panel may contain a limited number of missing or flickering pixels.
- 5 If the monitor is left on continuously over a long period of time, dark smudges or burn-in may appear. To maximize the life of the monitor, we recommend the monitor be turned off periodically.
